Salient Features and Specialities:

• Specially Designed for 300oC fluid  (Hot Oil / Steam / Hot water / Cold Water)
• Longer life
• Compact design
• Corrosion resistant
• Low pressure drop
• Spring closing arrangements for the prevention of reverse flow the pipelines.
• These valves are general purpose valves that are stronger, lighter and smaller than conventional swing check valves and therefore, less expensive to install and maintain.
• Suitable for higher pressure /temperature (up to 400oC).
• Compact design for simple installation between wide ranges of flange types.
• It can be mounted in any plane/direction.
• Extremely low opening pressures.
• Spring assisted silent closing.
• Available sizes 15mm to 100mm,suitable for PN6-PN40 and 150/300.
• Weight and Dimension are same for class 150 & class 300 valves.
• Valves are self-centering type.
• Zero leakage for soft seated valves.
• The maximum permissible leakage rate shall be 3 cubic centimeters per inch of nominal pipe size for metal-seated valves.
